Polymaker PolyMax PC Filament

PolyMax™ PC

PolyMax™ is a family of advanced 3D printing filaments produced with Polymaker’s Nano-reinforcement technology, to deliver exceptional mechanical properties and printing quality.

PolyMax™ PC (formerly known as PC-Max™) is an engineered PC filament combining excellent strength, toughness, heat resistance and printing quality. It is the ideal choice for a wide range of engineering applications.

FEATURES

Excellent Toughness - An excellent choice for engineering applications, PolyMax™ PC offers best in class toughness with much improved mechanical strength when compared to ABS and ASA and significantly improved impact resistance when compared to PolyLite™ PC.

Heat Resistant - PolyMax™ PC offers better heat resistance than a wide variety of material types, withstanding temperatures well above 110 ºC.

Improved Printability - PolyMax™ PC has been engineered specifically with compatibility and usability in mind. PolyMax™ PC not only offers excellent properties and print quality, but also improved printability when compared to other PC filaments. 90°C heated bed required.

Uncompromised Quality - Polymakers leading quality control process and rigorous in-house testing ensure reliable printing and consistency across spools and batches.

Find a reseller

Technology

PolyMax™ PC features Polymaker's Nano-reinforcement technology:

Nano-reinforcement - Nano-reinforcement technology is applied to produce filaments with excellent mechanical properties and printing quality. It dramatically improves the toughness of the material by increasing its impact resistance.

Print Settings

Nozzle Temperature:
250˚C – 270˚C


Printing Speed:
30mm/s – 50mm/s


Bed Temperature:
90˚C – 105˚C


Bed Surface:
BuildTak®


Cooling Fan:
OFF


Note: Based on 0.4 mm nozzle and Simplify 3D v.3.1. Printing conditions may vary with different printers and nozzle diameters

Mechanical Properties

Young’s Modulus:
2048 ± 66 Mpa


Tensile Strength:
59.7 ± 1.8 Mpa


Bending Strength:
94.1 ± 0.9 Mpa


Impact Strength:
25.1 ± 1.9 kJ/m2

Compare

Thermal Properties

Glass Transition Temperature:
113˚C


Vicat Softening Temperature:
117˚C


Melting Temperature:
N/A

Compare

Notes

Recommended Support Materials:
PolyDissolve™ S2


Other:
When printing with PolyMax™ PC it is recommended to use an enclosure. For large parts it is recommended to use a heated chamber.

It is recommended to anneal the printed part right after the printing process to release the residual internal stress.

Annealing settings: 100˚C for 2h


Technical Data Sheets:
Contact your local reseller


Safety Data Sheets:
Contact your local reseller
